Curtain Track, type EF-1000 is designed specially for small and medium weight curtain in auditorium, Conference Hall, Television Studio back ground and cyclorama curtain. Cotton / Silk curtain is suspended from curtain trolleys using S hooks or tape. Curtain trolleys with Nylon rollers and brass bush for noise free operation move on tracks. Trolleys can support curtain weight of 5 Kg per trolley. Five trolled per meter is recommended. Curtain can be moved either by Electric winch, manual drive or just by pulling by hand on hand line pulley.

Curtain track is built of all steel section in welded construction, electro zinc plated and passivated. Sections are made in standard lengths of 1 mtr, which are assembled with nut, bolt and using various accessories. All 1Mtr Long sections are identical and inter-changeable, they have standard jointing holes. Curtain tracks are also available in curve sections to suit specific application requirement.

Tracks are suspended by adjustable track supports of various design to suit installation requirements. Curtain track accessories of Divertor Pulleys, Tension Pulleys, Master and Slave trolleys, Steel rope clamps and Drives are available as standard. Centre opening Main Curtain installation of Auditorium, Cinema and Theatre require centre overlap of minimum 1.5 Mtr the track should be long enough, on both sides of the proscenium, to allow gathered curtain to clear proscenium, when curtain is fully open and also allow for installation of pulleys.

Curtain and curtain accessories have been engineered out of long years of experience in providing professional equipment to entertainment industry. Large variety of clamps, suspension brackets, spacers, pulleys, electric winches, hand winches and hand line pulley are made as standard equipment.

Variety of ropes in steel cotton and nylon or mix can be used to suit specific requirement, Our design group can be contacted for a comprehensive cost effective package involving design, supply and installation
